LAS8002G Glass Door Drop Seal
face-fixed
A slimline, face-fixed drop seal suitable for glass doors -hinged into timber or aluminium frames. A smooth backplate creates a visual aesthetic. LAS8002G si features a high efficiency mechanism, which lifts the seal clear of the floor as soon as the door is opened by a few millimetres; resulting in lower door operating forces.
Finish
System specification
| Property | |
|---|---|
| LOCATION | Single swing doors. For use on both right + left handed doors |
| MIN/MAX GAP SIZES | 1mm/10mm |
| SEAL MATERIAL | Grey silicone rubber |
| Standard finish | Silver anodised aluminium with grey end caps and grey silicone rubber gasket as standard |
| Non-standard finish | Bronze anodised aluminium with black end caps and black silicone rubber gasket are subject to non-standard charges and additional lead times. Other powder-coated colour finishes (non-standard - charges and lead times apply) |
| STANDARD LENGTHS | 335mm, 435mm, 535mm, 635mm, 735mm, 835mm, 935mm, 1035mm, 1135mm + 1235mm. Note: Each length can be cut back to the next size down. The 335mm can be cut back to 255mm. |
| ADJUSTMENT | Self-levelling on uneven surfaces. Can be adjusted independently of the fixing screws |
| TEST EVIDENCE | Durability: 1 million cycles |
